Granule Vertical Automatic Packaging Machine – Powder & Particle Weighing & Bagging System

1. Key switch + full digital display. The operation is stable and reliable.

2. Computer controlled, the system adopts stepper motor subdivision technology, with high bag making accuracy and an error of less than 1 mm.

3. Fully automatic tracking of color marks, intelligent elimination of false color marks, and automatic completion of positioning and length determination of packaging bags.

4. Heat sealing has dual-channel temperature control, intelligent temperature control, good thermal balance, ensuring sealing quality, and is suitable for a variety of packaging materials.

5. Intelligent photoelectric color mark positioning control system.

6. Using the latest shaker-type cup adjustment device, the packaging capacity can be adjusted at any time during the operation of the machine, reducing material loss and improving work efficiency.

The main function:

Automatically complete all tasks such as measurement, bag making, filling, sealing, printing batch numbers, cutting and counting; automatically complete the packaging of granules, fluids and semi-fluids, powders, tablets, and capsules.

Adaptable packaging materials:

Filter paper tea bag, tea bag roll, PE film, Paper/polyethylene, cellophane/polyethylene, polypropylene/polyethylene, polyester/aluminum foil/polyethylene, polyester/aluminized/polyethylene, nylon/polyethylene, polyester/polyethylene and other composite materials.

Technical parameters:

Model: DP-120

Packaging speed (bag/min) 55-100 40-60

Measuring range (ml) 2-50 20-100

Bag size (mm) (L)50-115 (W)30-85 (L)80-145 (W)30-100

Bag making method: three-side sealing

Measuring method Container type Container type

Power (Kw) 0.86 0.86

Weight (Kg) 230 230

Overall dimensions L*W*H: 695X770X1580(mm)

Packaging material diameter ≤300 mm
