Film-stretching Instrument | Laboratory Film Stretching Machine

Film-stretching instrument, also known as a laboratory film stretching machine, is used to evaluate mechanical properties of polymer films under controlled tension and temperature.

Film-stretching Instrument | LaboratoryFilm Stretching Machine

APPLICATION

New product development in the feld of high-end film.

Test and analyze physical and chemical properties of new material film forming

Formulation design of high-end film.

Process research and parameter oplimization.

ModelFOHI-10 Applicable materialsPE, PP, PET,PTFE, PVDF, etc. Sample thickness0.02-2mm Min.95mm×95mm Max.110 mm×110 mm Stretching ratio10:1（min. sample） Stretching speed0-500mm/s (stepless variable) Stretching force2000Nm Clamp pressure2.5MPa Operating temperatureRoom temperature-350°C Operating temperature accuracy±3℃ Stretching motor power3.5kW Working voltage3φ380VAC±10%，1φ220VAC±10%，50Hz Rated power Approx.83kW L x W x H5000mm×2100mm×1900mm WeightApprox.5000kg

Product Specifications

Product Date 2026
Delivery cycle within 1 month
Customize Support
Price Quotation
Exit Support
OEM Quotation
Supplier Guangzhou POTOP Co., Ltd.
Delivery Method Land transport/Ocean transport, etc.
User Manual provide
Shippable Areas Southeast Asia and Global

Procurement Recommendation

Film-stretching instrument: lab-grade machine for tensile testing of polymer films; verify speed control, force accuracy, and ASTM D882 compliance (for reference only).

Due to market conditions, product updates, and policy changes, please contact the supplier for the latest information.
